Microprocessor Based Controller with Digital Temperature Display of Temperature in Centigrade With Microprocessor base single channel Real time Data Logger.: Temperature Range selectable with setting accuracy of + 0.1 degree C. Logging time from 1 min to 99 Min selectable. Memory of 1000 counts with alarm history. Communication port – Rs. 232 or Rs 485. Centronics Port – for dot matrix printer.Suitable for external monitoring. With Window base software. Analysis of word print and graph.
User parameter settings - Set point, Audio Visual Alarm system for Over and Under temperature, Buzzer Off.
Audio Visual alarm system for temperature fluctuation and power failure is independent of power Supply. Suitable battery back up of 4 hours including charger for Temperature Controller, Data logger & alarm to check temperature conditions during power failure.
Seven days inkless graphic temperature recorder with Temperature range 0 deg C to - 50 deg C
Performance is independent of electrical fluctuation. Control system with two temperature sensors & independent safety thermostat to avoid negative temperature.
Outside : C. R. sheet of, Duly Powder Coated after Seven Tank Surface treatment.
Inside : Non- Magnetic AISI 304 Stainless Steel with properly Perforated & internal lighting.
Drawers : Rolled out type Stainless steel with inventory racks.
Copper : Interior Copper of refrigerator confirming to ASTMB Grade 68.
Door : Thickness 100 mm Polyurethane insulation.Automatic Front door closing below door opening angle of 90 with Door locks.
Inner door to prevent loss of cold air.
Door opening audio & visual display alarm.
Lockable Castor Wheel provided for Easy Mobility for Installation.
Constructed for Noise free and Vibration free performance with condensation free frame.
Input Voltage : 220/240 AC Volts, 50 Hz/1Phase A Line Voltage Corrector: Input Voltage: 160V-260V, 50Hz /1 Phase.
Output Voltage : 220v-240v AC Volts.
|JA DF -80
||Inner: H(1320mm) x W(510mm) x L (560mm)
Outer: H(2100mm) x W(830mm) x L (810mm)
